Теоритическое исследование обработки междурядий хлопчатника с фрезерными рабочими органами при посеве пшеницы

Поделитесь статьей с друзьями:
Автор(ы): Мавланов Фахриддин Хакимович, Рахимов Хурсанд Мадрахим угли
Рубрика: Технические науки
Журнал: «Евразийский Научный Журнал №8 2016»  (август)
Количество просмотров статьи: 1104
Показать PDF версию Теоритическое исследование обработки междурядий хлопчатника с фрезерными рабочими органами при посеве пшеницы

Мавлонов Фахраддин Хакимович
Teacher of the department of «System transport» of UrSU.
Преподаватель кафедры «Транспортные системы» УрГУ.
Ургенч, Узбекистан

Рахимов Хурсанд Мадрахим угли
Student of the specialty “Upper Earth Transportation ” of UrSU.
Студент специалности “Надземние транспортние системы” УрГУ.
Ургенч, Узбекистан

The following article gives information on contemporary condition of seeding wheat between cotton-plant row spaces, its deficiencies and not implementing agro technics of seeding wheat. The opportunities of treating with mill cutter apparatus, necessary measures of mill cutter drum and the kinematics of transferring movement to it is learned to prepare the layer of soil of the field on agro technical standards on preparing cotton-plant row spaces to seed wheat with the assistance of cultivators. The graphic of choosing λ, the kinematic regime indicator, is shown based on largeness of clods on agro technical standards and the number of knifes in mill cutter drum.

В статье изучено параметры и кинематикии фрезерного рабочего органа, для подготовки посева зерновых культур с культиватором на междурядий  хлопчатника. Приведены информации о положении сева междурядьеях зерновых, недостатки и о невыполнении требований агротехники сева пшеницы. При подготовке междурядий  хлопчатника к севу пшеницы в целях снижение комковатости почвы и обеспечения требованим агротехники изучены возможности использования фрезерные рабочие органы. Так же изучены необходимые параметры и кинематике передачи привода фрезерного рабочего органа.

This know that offer the grain independence  (Uzbekistan), planting grain in autumn reason in the rows of cotton plant has been carried out in September and October due to the provision of the need of the population for seed production and using the fields with sensibility mostly grain is being planted in the arcos tendered once or twice treated for an go centimeter interval of the rows with KXU- 4 cultivator fertilizer when the rows intervals are go as well treated for a 50 centimeter interval of the rows with KPX-4 cultivator fertilizer when the rows intervals are 60 cm. Treating depth is 12-14 cm in it, at first flattening organs of the planted grain are placed into the cultivators. It is necessary to get provision of the distribution on the surface of the fields of the particular flattening plating depth according to the agro-technical terms in scientific technical organizing replanting.

Without this method above, the surface of the field. Should be lumpy we ve mentioned about the technology of planting into the cotton plant rows in literature [1].

Namely spreading grain in once or twice treated row intervals with cultivator fertilizers and burying them with working organs. Although all agro technical terms are taken into consideration, 30…60 percent can’t be grown and seed in the fields can’t be smoothly distributed. That’s why using this type of crop dusted and well-chosen seed with sensibility leads to the great economical effectiveness (in Khoreesm (Uzb)) annually if the grain is planted in the cotton plants in 2500 acre, if 50 kg of seed are economize in each acre it will be 1250 ton grain.

In most cases autumn seasonal wheat is planted into cotton rows by cultivating the field,  not watering. It might cause occurring different seized lumps over the surface of the field. As a result seed of wheat may fall down under lumps and lose their growing ability smoothly distribution over the field. In its own turn later it may reduce working quality in planting process.

If wheat is planted by using (sunshine) large lumps and weed grass in the fields can damage to the (“soshniks” planting equality).

First of all to plant wheat into cotton rows the area must be prepared according to the agrotechnie demands [2].

Namely the seer face of the sand layer must be 0-10 cm, separated structural in depth, numbers should be 1-3 mm (80%) [3],  macsimum measurement of lump shouldn’t be more that 2-3cm [4]. For that due to the flattening the sand in the rows, threshing from weed grass, at first, it is treated with cultivators in 15-10cm. In spite of Being-trcated twice the sand on the surface of the field mostly couldn’t provide the demands above. The reason is here not being supplied enough wetness before being treated in the cotton rows , namely watering can’t be made for some reason (eg? Hardest process, lack of water or etc). As a result the sand dries up, its surface gets more lumpy after being treated. And it radically reduces the quality and chances of planting wheat.

For this purpose in this article theoretical teating with foresail working organ with the help of cultivator due to making normal conditions in the first treating into the cotton rows.

Working organs of frees are cooled active working organs when they are made to be circled from the power of the tractor. Freezes are divided into forest, jungles field, garden and plant rows cutting down sorts according  to their functions. Tiled frizz are used for getting prepared the fields areas to plant in spring by mincing lumps. Chopping frezs are used in the cotton rows threshing the earth from weed grass and softening it as well.

Circling point of the frees in agriculture is vertically and horizontally.

In most cases working organs of the freezes go around horizontally to their movement directions. They consist of knives in the shape of raround the discus circulation (Figure 1, 1-2 knives). The collection of these types of discs forms freesias drum. The number of the knives are mostly taken 4 or 8 according to their functions. The shape and measurement of the knives depend on the functions conditions of the freeze. The knive may turn cound from up to down from down to up, namely the opposite side of the car. While turning round to the straight power may occur, which tries the car to move straight, on the opposite turning round, the energy is demanded more.

That’s why turning round to the straight is demanded in all field frezs opposite turning is used in stone zones and the forests. The knive can be jointed with the discs bikr, prujinali, sharnirlr. In the field frezs they are fixed fixing is used in stone areas, fixing can be demanded in speedy frezs digging torf [5].

Freeze dreams goes round horizontally and participates in 2 movements round its point out a speed of Vо (elative movement) and with car at a speed of Vm moving movement. Each lump of the sand in the disc, its form and measure depend on rounding side of the drum and the form of moving traces of the 2 knive established one by one vertically in the disc sand. In treating tods to the sand it is give in literatures the frez drums radius is determined dependently on the thickness of the layer [5].

Д=(2,5…3,5)а     (1)

Here: a-treating depth (figure 1), if it is 10 cm, then D=30 cm and R=15 cm.

One periling out distance of a cycling freeze knife ХZ (figure 1) is considered the main factor determining the shape of the lumps occurring in the sand. It is chosen according to the fields conditions or counted by the following formula [5].

Формула 2.PNG

z –  the numbers of the knives in the drum.

λ – kinematic regime. Its clarified with the speed of freeze.

λ= Vо/ Vm        (3)

(in the sand freeze λ=2…6 is accepted).

It’s known from the formula 2 knives periling distance can be reduced by rising λ and z numbers of the freeze knives.

The formula 2 can be the following, if kinematic regime is identified

Формула 4.PNG

If  ХZ, R, z   are accounted (the numbers of the knives z=4…8) and lumps measurement in maximum is 3 cm, then it is λ=3,9 and it is accepted basing an λ≥3,9.

Given accounts of λ, ХZ, z and their interdependence shown in figure 2, the shape of the lump and on the basis of the λ may rise radically, if the shape of the lump is 1cm after having been treated, either reducing the speed of the tractor or rising cycling speed of the freeze drums can solve this matter.

It can be clear from all above the cycling speed of the drum must be more at least 3,9 degrees than the aggregate’s forwarding speed. In this case the shape of the lumps on the surface of fields can be satisfactory for the terms of the agro techniques at minimum degree (ХZ=3 cm).


Figure 1. Movement trace of the working organs of the freeze. 1,2 –freeze knives, ХZ -the sand thickness, R-the radius of the freeze drum.


Figure 2. the graphics of choosing λ, the level of the kinematic remise. z=4, z=6, z =8 – numbers of the knives.

We determine the speed of treating sand preparing rows for planting grain, if it is Vм=1,68 m/c, ХZ =3, z=8, λ=3,9  of  Vо=6,52 m/c, ω=43 1/sek, п=411 ob/min.

All in all the condition of the ХZ and z for the other amounts λ in figure 2 is identified, necessary parameter of distributing movement to the ferial drum according to the conditions of the cotton fields.

 In the next steps of the research fixing ferial drums into the back sections can be theoretically investigated. In those the width and weight of the ferial drum based on cotton rows intervals can be geometrically and the other work my be done.

Used Literature

  1. I. Ro’zmetov,  F. Mavlanov.  Xorazm environment cotton  line’s interval autumn wheat souring condition. Urganch, UrSU, “Ilim sarchashmalari” magazine. №-3, 2008-y, p-4.

  2. I. Ro’zmetov,  F. Mavlanov. “Projected sowing apparatus with cotton line’s interval the reason of sowing wheat”. Toshkent, TashSTU,  “ToshDTU Xabarlari” 1-2- n, 2011-y, p-4.

  3. www.Agrosp.kiev.ua. Технология выращивания пшеницы озимой. 2014 г.

  4. I.Qobulov. “The technology of rearing autumn grain crops. Andijon, “ Xayot nashiryoti”, 2014-y,  p-82.

  5. A.Hamidov. “Planning agriculture machine“.  Toshkent,  “O’qituvchi”, 1991-y, p-248.
